Ourdoor Storage Cantilever Rack
Five Advantages Of Products
- Excellent low-cost storage system!
- Store long products with ease. Unobstructed arms afford easy accessibility with no uprights on the aisle to restrict storage.
- Arms adjust easily on 100mm centers.
- Easy assembly, no special tools required.
- Upright construction from bolted post and foot profiles can also be retrofitted to either a single face or double faced systems by changing the foot profile.
Product Details
Product Details
Outdoor storage cantilever rack with its versatility offer maximum support, strength and capacity for storing lumber and other long, flat items with ease. It is found in daily use in all sectors of industry.
Outdoor storage cantilever rack is highly load-bearing storage systems intended for storage of long and/or bulky storage materials. Such goods include, for example timber, wooden boards, metal sheets, sections, beams or steel elements, building materials but also scrap cars and all kinds of heavy loads.
Outdoor storage cantilever rack by Welfor is distinguished from standard racks using solid steel sections for all load-bearing elements. Thanks to this slim construction of our racks a high storage capacity can be achieved across a small floor space.
Features
●Robust design, high stability. The uprights and feet are made from hot rolled IPE profile and are bolted together to form a rigid cantilever frame. Large footplates ensure even distribution of the load to the floor.
●Upright construction from bolted post and foot profiles can also be retrofitted to either a single face or double faced systems by changing the foot profile.
●Uprights are bolted together with horizontal braces to form racking rows and reinforced with vertical cross bracing in every fourth racking bays.
●Arms are adjustable every 100mm.
●Bolted cantilever arms.
●Simple assembly with few components.
●Applications range from manual to automatic operation, stationary or mobile racks.
●Racks can be installed indoors or outdoors as required.
●Load capacity up to 14000 kg per upright side based on evenly spaced cantilever arms.
Advantages
●Excellent low-cost storage system!
●Store long products with ease. Unobstructed arms afford easy accessibility with no uprights on the aisle to restrict storage.
●Arms adjust easily on 100mm centers.
●Easy assembly, no special tools required.
